LED Linear Light

LED Linear Light LL-XC Series

Model: JST-LL-XC

Wattage: 10W-20W

LED Chip: OSRAM

Driver Brand: Lifud

RA: 80/90/97

IP Rate: IP65

Beam Angle: 15°/24°/36°

Finish Color: White/Black/Customized

Size: See Below

Installnation: Surface Mounted/ Wall Mounted

Description

The LL-XC series wall lamps are meticulously crafted IP65-rated linear luminaires by JARSTAR,specifically designed for indoor and outdoor wall lighting.This series of wall lamps stands out among a multitude of lighting products with its excellent performance,stylish appearance,and flexible installation methods,providing an ideal lighting solution for various spaces.


How to choose the size of the wall lamp?

It depends on the installation environment and the size of the space, the height of the bedroom wall light is generally between 1.4-1.7 meters, and the study wall light should be 1.4-1.8 meters away from the desktop and 2.2-2.65 meters from the ground. At the same time, the wall lamp should also match the architectural style of the house, and you can consider the design of open or closed cover.


What are the materials of wall lamps?

The glass material has high transparency and good texture, which is suitable for living room, bedroom, etc.

The ceramic material has a unique texture and strong light transmittance, which is suitable for restaurants, toilets, etc.

The metal material has excellent load-bearing performance, which is suitable for use in hotels, shopping malls and other public places.

The wood material is simple and natural, which is suitable for use in children's rooms and other home places. The warm tones of the wood sconces create a soft, cozy atmosphere.

Advantages
Specification
Model
PowerCRI
CCTInput VoltageBeam Angle
Dimension
Installnation
XL004-IP65-5T
12W80/90/97
2700-6500KAC220-240V15°/24°/36°161*59mm
Surface Mounted/ Wall Mounted
XC004-IP65-5T12W80/90/972700-6500KAC220-240V15°/24°/36°151*49*91mmSurface Mounted/ Wall Mounted
XW004-IP65-5T12W80/90/972700-6500KAC220-240V15°/24°/36°151*73*123mmSurface Mounted/ Wall Mounted

XC004R-IP65-4T

10W80/90/972700-6500KAC220-240V15°/24°/36°88*91mm
Surface Mounted/ Wall Mounted
XC004S-IP65-4T10W80/90/972700-6500KAC220-240V15°/24°/36°80*80*91mmSurface Mounted/ Wall Mounted
XW004R-IP65-4T10W80/90/972700-6500KAC220-240V15°/24°/36°88*113*123mmSurface Mounted/ Wall Mounted
XW004S-IP65-4T10W80/90/972700-6500KAC220-240V15°/24°/36°78*103*123mmSurface Mounted/ Wall Mounted
XC004S-IP65-9T20W80/90/972700-6500KAC220-240V15°/24°/36°110*110*91mmSurface Mounted/ Wall Mounted


Application

Commercial spaces lighting, Office lighting, Clubs lighting, Residential areas lighting, Schools lighting, Restaurants lighting, Museums lighting, Hotels lighting, Showrooms lighting, Jewelry stores lighting,Banks lighting, Airport lighting, Suppermaket lighting, Art galleries lighting, Villas lighting, Bars lighting, Exhibition halls lighting etc.
